Heroal

deck height - 37 mm
profile height - 42,5 mm
profile thickness - 8 mm
max. width - 3000 mm
max. height - 3500 mm
max. surface area - 6.2 m²
number of slats in 1 m height - 27 pieces
weight p/m² - 3,5 kg

The main advantages of the heroic RS 37: the roller shutter can be rolled up very tightly and has a small roll-up diameter (Ø 163 mm with an armour height of 2500 mm). This is possible thanks to the use of the finest slat in the heroal range (nominal thickness only 8 mm) - a perfect solution for situations where very small cabinet sizes are required.

height - 41 mm
profile height - 48 mm
profile thickness - 8.5 mm
max. width - 3500 mm
max. height - 3500 mm
max. area - 7,0 m²
number of slats in 1 m height - 25 pieces
weight p/m² - 3.7 kg

Ideally suited for use in small roller shutter boxes (pipe diameter Ø 185 mm at a height of 2,500 mm). The very stable profile of the roller shutter with a low weight (3.7 kg/m²) meets wind load class 3 for elements up to 2900 mm wide.

height - 42 mm
profile height - 48 mm
profile thickness - 9.3 mm
max. width - 3500 mm
max. height - 3500 mm
max. area - 7,0 m²
number of slats in 1 m height - 24 pieces
weight p/m² - 3.9 kg

The HK-842 profile, thanks to its robust wall thickness of 9.3 mm, achieves very good resistance for 3 wind classes with a width of 2900 mm.

height - 38 mm
profile height - 45 mm
profile thickness - 9.0 mm
max. width - 3700 mm
max. height - 3800 mm
max. area - 8,0 m²
number of slats in 1 m height - 27 pieces
weight p/m² - 4.5 kg

The heroal Mini E is a safe roller shutter solution especially for regions with high wind loads. Excellent wind load values - resistance class 4 for element widths up to 2,600 mm - are the result of the high stability of this roller shutter slat.

height - 32 mm
profile height - 40 mm
profile thickness - 8.5 mm
max. width - 3700 mm
max. height - 3500 mm
max. area - 7,5 m²
number of slats in 1 m height - 32 pieces
weight p/m² - 4.8 kg

The small deck width of 32 mm makes the heroal Super Mini E - the smallest roller shutter slat in the system - so strong. Thanks to its compact design and element width of 2,700 mm, it meets the requirements of wind resistance class 3.

height - 37 mm
profile height - 45 mm
profile thickness - 9,0 mm
max. width - 4000 mm
max. height - 4000 mm
max. area - 9,0 m²
number of slats in 1 m height - 27 pieces
weight p/m² - 5,9 kg

The exceptional material strength and special foam mixture make the heroal HL-837 an unrivalled highly stable roller shutter pole. It meets the requirements of wind resistance class 4 for element widths up to 3,000 mm as well as the BVRS guideline TR 111 in the area of burglary protection.

height - 54 mm
profile height - 61 mm
profile thickness - 13,5 mm
max. width - 4500 mm
max. height - 3800 mm
max. area - 9,0 m²
number of slats in 1 m height -19 pieces
weight p/m² - 4,2 kg

The outstanding winding characteristics of the 50 series also distinguish the heroal ER-54. The perfect rod geometry ensures the small bale diameter (Ø 210 mm bale diameter with a shell height of 2,800 mm). This means that the rod can also be used in conventional front-mounted roller shutter systems with the smallest box sizes.

height - 37 mm
profile height - 45 mm
profile thickness - 9.5 mm
max. width - 4200 mm
max. height - 4000 mm
max. area - 10,5 m²
number of slats in 1 m height - 27 pieces
weight p/m² - 8.0 kg

The heavy-duty two-component integral material foam gives the filigree rod heroal Mini Safe its extreme bending strength and stability at a weight of 8.0 kg/m2. With a cover width of 37 mm and a nominal thickness of 9.5 mm, the rod is tested and approved up to resistance class RC 2 according to DIN 1627. In addition, the heroal Mini Safe was awarded hail class 6.
